html 对 div 进行 拉伸 拖拽

2018-10-26 08:35:50

火狐浏览器支持不好 , ie不能用.....谷歌最好

代码也有bug,快速操作的时候会出现小浮动的偏移 , 不能两个一块拖动

在网上看到有这个功能就自己写了一个,写的不好有简单的方法可以留言指正谢谢!


<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml">
<head>
<meta http-equiv="Content-Type" content="text/html; charset=utf-8" />
<title>拖动事件</title>

<style>
.s-move-content-outer{border:1px black solid;width:200px;height:200px;position:relative;outline:none;user-select:none;/*overflow:hidden;*/}
/*.s-move-content-outer:focus .s-show{display:block;}*/
    /* 移动 */
    .s-move-content-header{background-color:pink;width:100%;height:30px;text-align:center;line-height:30px;cursor:move;}
	.s-move-content-header:focus .s-show{display:block;}

	/* 内容 */
	.s-move-content-content{font-family:华文行楷;width:100%;height:100%;background-color:red;}
	/* 八个方位的div控制 */
	.s-move-content-direction{width:5px;height:5px;border:1px black solid;background-color:gray;position:absolute;display:none;}
	/* 八个方位的小手各自的div */
	.s-move-content-direction-n{cursor:n-resize;left:50%;top:-7px;margin-left:-4px;}
	.s-move-content-direction-ne{cursor:ne-resize;top:-7px;right:-7px;}
	.s-move-content-direction-e{cursor:e-resize;top:50%;right:-7px;margin-top:-4px;}
	.s-move-content-direction-se{cursor:se-resize;bottom:-7px;right:-7px;}
	.s-move-content-direction-s{cursor:s-resize;bottom:-7px;left:50%;margin-left:-4px;}
	.s-move-content-direction-sw{cursor:sw-resize;left:-7px;bottom:-7px;}
	.s-move-content-direction-w{cursor:w-resize;left:-7px;top:50%;margin-top:-4px;}
	.s-move-content-direction-nw{cursor:nw-resize;left:-7px;top:-7px;}

</style>


</head>

<body>

<div class="s-move-content-outer" tabIndex="1" >
    <div class="s-move-content-header" tabIndex="1" >请移动我
        <div class="s-move-content-direction s-show s-move-content-direction-n"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-ne"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-e"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-se"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-s"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-sw"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-w"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-nw"></div>
    </div>
    <textarea style="width:100%;height:170px;box-sizing: border-box;" ></textarea>
</div>

<!--
<div class="s-move-content-outer" tabIndex="1" >
    <div class="s-move-content-header" tabIndex="1" >请移动俺
        <div class="s-move-content-direction s-show s-move-content-direction-n"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-ne"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-e"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-se"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-s"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-sw"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-w"></div>
        <div class="s-move-content-direction s-show s-move-content-direction-nw"></div>
    </div>
    <textarea style="width:100%;height:170px;box-sizing: border-box;" ></textarea>
</div>
-->

</body>
</html>

<script>

var ele = document.getElementsByClassName("s-move-content-outer")[0];
//var ele1 = document.getElementsByClassName("s-move-content-outer")[1];
document.onmousemove = function(e){
	addMoveContentControl(ele,e);
//	addMoveContentControl(ele1,e);
}


</script>

<script>

var space = {
	move : {              // [移动]
		content : {           // [移动备注框]
			width  : 200,         // 默认div的宽度
			height : 200,         // 默认div的高度
			top    : 0 ,          // 默认div的距离头部距离
			right  : 0 ,          // 默认div的距离右侧距离
			bottom : 0 ,          // 默认div的距离底部距离
			left   : 0 ,          // 默认div的距离左侧距离
			moveHeight : 30 ,     // 默认头部高度
			textareaHeight : 170, // 默认textarea的高度
			min    : 100 ,        // div宽度高度不能小于min
			buttomTarget : null,  // 鼠标按下之后的target
			moveTarget : null     // 鼠标按下之后移动的target
		}
	}
}

/**
 * @para divEle 最大的div
 * @para e      鼠标事件
 */
function addMoveContentSuper(divEle,e){
	// 缩小保护
	this.min = space.move.content.min;

	// 所有元素
	this.divEle    = divEle;
	this.textEle   = ele.lastElementChild; // testArea element

	// 最大div的style
	this.divStyle  = this.divEle.style;
	this.divWidth  = this.divStyle.width;
	this.divHeight = this.divStyle.height;
	this.divTop    = this.divStyle.top;
	this.divRight  = this.divStyle.right;
	this.divBottom = this.divStyle.bottom;
	this.divLeft   = this.divStyle.left;

	// 头部移动高度
	this.hreadHeight = space.move.content.moveHeight;

	// textarray的style
	this.textStyle   = this.textEle.style;

	// 鼠标事件event
	this.e = e;
	this.x = e.movementX;
	this.y = e.movementY;
	this.moveTarget = space.move.content.moveTarget; // 正在移动的target

	// 修改属性的值
	// [这里以后就不用再if判断了,就连html里的标签都是js生成的直接用js赋值宽度就行]
	this.divWidth  = (this.divWidth   === "") ?
	    space.move.content.width    : parseInt(this.divWidth.replace("px",""));

	this.divHeight = (this.divHeight  === "") ?
	    space.move.content.height   : parseInt(this.divHeight.replace("px",""));

	this.divTop    = (this.divTop     === "") ?
	    space.move.content.top      : parseInt(this.divTop.replace("px",""));

	this.divRight  = (this.divRight   === "") ?
	    space.move.content.right    : parseInt(this.divRight.replace("px",""));

	this.divBottom = (this.divBottom  === "") ?
	    space.move.content.bottom   : parseInt(this.divBottom.replace("px",""));

	this.divLeft   = (this.divLeft    === "") ?
	    space.move.content.left     : parseInt(this.divLeft.replace("px",""));

}

/**
 * 添加移动框的 移动 && 放大 && 缩小 && 斜拉
 *
 * 元素组织最大一层 div → 移动层 → 八个小方位
 *                ↓
 *               textarea
 * @param  {[divElement]}  divEle [需要移动的div,最外层的div]
 * @param  {[EventObject]} e      [event type='move']
 * @return {[void]}
 */
function addMoveContentControl(divEle,e){
	if(e.buttons !== 1){                               // 当鼠标没有按下则不走方法
		space.move.content.moveTarget = null;
		return;
	}else if(space.move.content.moveTarget === null){  // 当鼠标按下了,movetarget为空则赋值
		space.move.content.moveTarget = e.target;        // 这里利用了成员变量
	}
	var move = divEle.firstElementChild;                                                 // 获取头部移动元素
	var direction = divEle.getElementsByClassName("s-move-content-direction");           // 获取所有拉伸的节点
	switch(space.move.content.moveTarget){
		case move         : new addMoveContentMove(divEle,e,move);                break; // 头部移动
		case direction[0] : new addMoveContentTop(divEle,e,direction[0]);         break; // 上拉伸
		case direction[1] : new addMoveContentRightTop(divEle,e,direction[1]);    break; // 右上拉伸
		case direction[2] : new addMoveContentRight(divEle,e,direction[2]);       break; // 右拉伸
		case direction[3] : new addMoveContentRightButtom(divEle,e,direction[3]); break; // 右下拉伸
		case direction[4] : new addMoveContentButtom(divEle,e,direction[4]);      break; // 下拉伸
		case direction[5] : new addMoveContentLeftButtom(divEle,e,direction[5]);  break; // 左下拉伸
		case direction[6] : new addMoveContentLeft(divEle,e,direction[6]);        break; // 左上拉伸
		case direction[7] : new addMoveContentLeftTop(divEle,e,direction[7]);     break; // 左上拉伸
		default : break;
	}
}

function addMoveContentMove(divEle,e,thisEle){ // 移动
	addMoveContentSuper.apply(this,arguments);
	var top  = this.divTop + this.y;
	var left = this.divLeft + this.x;
	this.divStyle.top  = top + "px";
	this.divStyle.left = left + "px";
}

function addMoveContentTop(divEle,e,thisEle){ // 向上拉伸
	addMoveContentSuper.apply(this,arguments);
	var top    = this.divTop;
	var height = this.divHeight + (-this.y);
	if(height < this.min)
	    height = this.min;
	else
	    top = this.divTop + this.y;
	this.divStyle.top    = top + "px";
	this.divStyle.height = height + "px";
	this.textStyle.height = (height - this.hreadHeight) + "px";
}

function addMoveContentRightTop(divEle,e,thisEle){ // 右上拉伸
	addMoveContentSuper.apply(this,arguments);
	var top    = this.divTop;
	var width  = this.divWidth + this.x;
	var height = this.divHeight + (-this.y);
	if(height < this.min)
	    height = this.min;
	if(width < this.min)
	    width = this.min;
	else
	    top = this.divTop + this.y;
	this.divStyle.top    = top + "px";
	this.divStyle.width  = width + "px";
	this.divStyle.height = height + "px";
	this.textStyle.height = (height - this.hreadHeight) + "px";
}

function addMoveContentRight(divEle,e,thisEle){  // 右侧拉伸
	addMoveContentSuper.apply(this,arguments);
	var width   = this.divWidth + this.x;
	if(width < this.min)
	    width = this.min;
	this.divStyle.width   = width + "px";
}

function addMoveContentRightButtom(divEle,e,thisEle){ // 右下拉伸
	addMoveContentSuper.apply(this,arguments);
	var width  = this.divWidth + this.x;
	var height = this.divHeight + this.y;
	if(height < this.min)
	    height = this.min;
	if(width < this.min)
	    width = this.min;
	this.divStyle.width  = width + "px";
	this.divStyle.height = height + "px";
	this.textStyle.height = (height - this.hreadHeight) + "px";
}

function addMoveContentButtom(divEle,e,thisEle){ // 向下拉伸
	addMoveContentSuper.apply(this,arguments);
	var height = this.divHeight + this.y;
	if(height < this.min)
	    height = this.min;
	this.textStyle.height = (height - this.hreadHeight) + "px";
	this.divStyle.height = height + "px";
}

function addMoveContentLeftButtom(divEle,e,thisEle){ // 左下拉伸
	addMoveContentSuper.apply(this,arguments);
	var left   = this.divLeft;
	var width  = this.divWidth + (-this.x);
	var height = this.divHeight + this.y;
	if(height < this.min)
	    height = this.min;
	if(width < this.min)
		width = this.min;
	else
		left = this.divLeft + this.x;
	this.divStyle.width  = width + "px";
	this.divStyle.height = height + "px";
	this.divStyle.left = left + "px";
	this.textStyle.height = (height - this.hreadHeight) + "px";
}

function addMoveContentLeft(divEle,e,thisEle){ // 向左拉伸
	addMoveContentSuper.apply(this,arguments);
	var left    = this.divLeft;
	var width   = this.divWidth + (-this.x);
	if(width < this.min)
	    width = this.min;
	else
	    left = this.divLeft + this.x;
	this.divStyle.left    = left + "px";
	this.divStyle.width   = width + "px";
}

function addMoveContentLeftTop(divEle,e,thisEle){ // 左上拉伸
	addMoveContentSuper.apply(this,arguments);
	var top    = this.divTop;
	var left   = this.divLeft;
	var width  = this.divWidth + (-this.x);
	var height = this.divHeight + (-this.y);
	if(height < this.min)
	    height = this.min;
	else
	    top = this.divTop + this.y;
	if(width < this.min)
	    width = this.min;
	else
	    left = this.divLeft + this.x;
	this.divStyle.top    = top + "px";
	this.divStyle.left   = left + "px";
	this.divStyle.width  = width + "px";
	this.divStyle.height = height + "px";
	this.textStyle.height = (height - this.hreadHeight) + "px";
}


</script>
